GEPRC MOZ7 V2 FPV Drone - Analog / WTFPV (Without VTX Cam) H743 50A 2809 1450KV 6S LiPo

{{ product.price_format }}
{{ product.origin_price_format }}
Quantity:
SKU:{{ product.sku }}
Model: {{ product.model }}
weight: {{ product.weight }} Kilogram

{{ variable.name }}

{{ value.name }}


Specification

  • Model: GEPRC MOZ7 V2 Analog

  • Frame: GEP-MOZ7 V2

  • Wheelbase: 336mm

  • Top Plate Thickness: 2.5mm

  • Bottom Plate Thickness: 2.5mm

  • Clamp Plate Thickness: 3mm

  • Arms Thickness: 6mm

  • FC: TAKER H743 BT

  • MCU: STM32H743

  • Gyro: MPU6000&42688-P dual

  • Barometer: support

  • GPS: GEP-M1025

  • OSD:BetaFlight OSD w / AT7456E chip

  • ESC: GEP-4IN1ESC_32-50A

  • VTX: MATEN 5.8G 2.5W

  • Camera: CADDX RATEL2

  • Antenna: Momoda2-SMA-RHCP-170mm-Female

  • Power Connector: XT60E-M

  • Motor: SPEEDX2 2809-1450KV V1.1

  • Prop: HQ 7.5*3.7*3 3-blade-transparent grey

  • Weight: 782±10g

  • Receiver: PNP / ELRS 915M/2.4G GemX / TBSNanoRX

  • Recommended Battery: LiPo 6S 3300mAh / Lilon 8000mAh

  • Flight Time: 25 minutes (based on slow cruising tests; actual results may vary due to product differences, firmware version, flying style, and environment)

Includes

1 x GEPRC MOZ7 V2 FPV

2 x HQ 7.5*3.7*3 (2CW+2CCW)

2 x 15*250mm battery strap

1 x L-shaped screwdriver 1.5mm

1 x L-shaped screwdriver 2.0mm

1 x L-shaped screwdriver 3.0mm

1 x Spare screw pack

2 x Battery anti-slip pad

1 x Frequency pairing ejector pin

1 x VTX antenna

1 x tri-band stick antenna

Specification

  • Model: GEPRC MOZ7 V2 WTFPV

  • Frame: GEP-MOZ7 V2

  • Wheelbase: 336mm

  • Top Plate Thickness: 2.5mm

  • Bottom Plate Thickness: 2.5mm

  • Clamp Plate Thickness: 3mm

  • Arms Thickness: 6mm

  • FC: TAKER H743 BT

  • MCU: STM32H743

  • Gyro: MPU6000&42688-P dual

  • Barometer: support

  • GPS: GEP-M1025

  • OSD: BetaFlight OSD w / AT7456E chip

  • ESC: GEP-4IN1ESC_32-50A

  • VTX: None

  • Camera: None

  • Antenna: None

  • Power Connector: XT60E-M

  • Motor: SPEEDX2 2809-1450KV V1.1

  • Prop: HQ 7.5*3.7*3 3-blade-transparent grey

  • Weight: 764±10g

  • Receiver: PNP / ELRS 915M/2.4G GemX / TBSNanoRX

  • Recommended Battery: LiPo 6S 3300mAh / Lilon 8000mAh

  • Flight Time: 25 minutes (based on slow cruising tests; actual results may vary due to product differences, firmware version, flying style, and environment)

Includes

1 x GEPRC MOZ7 V2 FPV

2 x HQ 7.5*3.7*3 (2CW+2CCW)

2 x 15*250mm battery strap

1 x L-shaped screwdriver 1.5mm

1 x L-shaped screwdriver 2.0mm

1 x L-shaped screwdriver 3.0mm

1 x Spare screw pack

2 x Battery anti-slip pad

1 x Frequency pairing ejector pin

1 x tri-band stick antenna




Material: Carbon FibernFrame: GEP-MOZ7 V2nWheelbase: 336mmnTop Plate Thickness: 2.5mmnBottom Plate Thickness: 2.5mmnClamp Plate Thickness: 3mmnArms Thickness: 6mmnFC: TAKER H743 BTMCUnGyro: MPU6000&42688-P dualnBarometer: supportnGPS: GEP-M1025nOSD: BetaFlight OSD w / AT7456E chipnESC: GEP-4IN1ESC_32-50AnVTX: MATEN 5.8G 2.5WnMotor: SPEEDX2 2809-1450KV V1.1nProp: HQ 7.5*3.7*3 3-blade-transparent greynWeight: 782±10gnRecommended Battery: LiPo 6S 3300mAh / Lilon 8000mAhnFlight Time: 25 minutes (based on slow cruising tests; actual results may vary)nIncludes: Original Box, 2 x HQ 7.5*3.7*3 Propellers (2CW+2CCW), 2 x 15*250mm Battery Straps, L-shaped Screwdriver Set (1.5mm, 2.0mm, 3.0mm), Spare Screw Pack, 2 x Battery Anti-slip Pads, Frequency Pairing Ejector Pin, VTX Antenna, Tri-band Stick Antennannn**Unmatched Durability and Performance**nThe GEPRC MOZ7 V2 FPV Drone is a testament to the blend of durability and performance in the world of RC quadcopters. Crafted from robust carbon fiber, this drone is built to withstand the rigors of both indoor and outdoor flying. The aerodynamic design, featuring a wheelbase of 336mm and a top plate thickness of 2.5mm, ensures stability and control during high-speed maneuvers. The MOZ7 V2's lightweight build, at just 782±10g, allows for extended flight times of up to 25 minutes, perfect for enthusiasts seeking long-lasting adventures.nn**Versatile Flight Experience**nThe GEPRC MOZ7 V2 FPV Drone is designed for both beginners and seasoned pilots alike. It comes with a variety of configurations, including the Analog and WTFPV (Without VTX Cam) versions. The Analog version is equipped with a TAKER H743 BTMCU and a BetaFlight OSD w/ AT7456E chip, providing stable flight control and real-time data. The WTFPV version, on the other hand, is a stripped-down model without a VTX Cam, allowing for the freedom to customize your FPV setup as per your preferences. The MOZ7 V2 is compatible with various flight modes, including RC Quadcopter, which makes it an ideal choice for both casual and competitive flying.nn**Ready for Adventure**nWhether you're a hobbyist or a professional, the GEPRC MOZ7 V2 FPV Drone is the perfect companion for your aerial escapades. It comes with all the necessary components, including propellers, screwdrivers, and battery straps, to ensure you're ready to fly right out of the box. The drone's recommended battery range of LiPo 6S 3300mAh to Lilon 8000mAh ensures extended flight times, allowing you to explore the skies for longer periods. The MOZ7 V2's versatility and robustness make it an indispensable tool for both recreational and competitive flying, promising an unparalleled experience in the realm of RC quadcopters.
